# Webinar "Calculation of Lightning Protection Reliability for Any Facility for 30 Minutes using the ZANDZ Calculation Service". Page 1

 (held on October 18, 2017 at 11:00 Moscow time) Speaker: Denis Pozdnyakov, technical specialist for earthing and lightning protection The webinar is intended for: designers of lightning protection and earthing Venue: online. What do you need to take part in the webinar? PC, Internet access, headphones. Price: free of charge. Webinar duration: 30 minutes. Computing core of the calculation service is developed by the Krzhizhanovsky Energy Institute (“ENIN” AO) in the laboratory for mathematical modelling of geophysical processes under the guidance of E.M. Bazelyan who was actively involved in the development of regulatory documents RD 34.21.122-87 and SO 153-34.21.122-2003. Answers to the questions regarding the webinar and the service for calculation of the lightning protection reliability are provided in a separate page. 720p full screen watching is recommended.

## Webinar text. Page 1

Service for calculation of the lightning protection reliability

 Сервис расчетов надежности молниезащиты Service for calculation of the lightning protection reliability Поздняков Д.В. D.V. Pozdnyakov Технический центр ZANDZ ZANDZ Technical Center ГК «ИМАГ» IMAG Group Заземление и молниезащита на ZANDZ.com Earthing and lightning protection at ZANDZ.com

– Good afternoon, dear colleagues! I am happy to greet everyone. Today, the webinar is dedicated to, as Anatoly has already mentioned, the service for calculation of the lightning protection reliability. We well talk about what this service is, how to access it, and how it is related to the regulatory documents. We will study a small example and see what results we can obtain.

What do the regulatory documents state?

 Что говорят действующие НТД? What do the regulatory documents state? Действующие НТД: СО 153-34.21.122-2003 Рз = 0,9-0,999 РД 34.21.122-87 Рз = 0,995 и 0,95 для зон защиты А и Б Effective regulatory documents: SO 153-34.21.122-2003 Рp = 0.9–0.999 RD 34.21.122-87 Рp = 0.995 and 0.95 for protection zones A and B Виды молниеотводов, к которым применимы формулы в СО: Types of lightning arresters to which the formulas in SO are applied: - одиночный стержневой - single rod, - одиночный тросовый; - single wire, - двойной стержневой - double rod, - замкнутый тросовый - closed wire

– Let's start with what we have got today. Today, to provide the lightning protection, we have two effective regulatory documents, SO-153-34.21.122-2003 and RD 34.21.122-87, at once. What do these regulatory documents define? In SO-153 and RD 34, such parameters as the lightning protection reliability are used. Thus, in regulatory document SO-153, such lightning protection reliability value is 0.9 to 0.999, but there is also the third value of 0.99. Thus, in the formulas provided therein, these values and the respective formulas are specified that can be used to calculate the protection zones, which will correspond to the specified reliability of the lightning protection system. In RD 34, this parameter is defined as follows: we have got two protection zones — zone A and zone B, and, respectively, they are assigned the reliability values for the lightning protection system of 0.995 and 0.95 for zone A and zone B, respectively. How do the regulatory documents describe these parameters? In SO-153, there is item 3.3.1 that states: "The facility is considered to be protected if a set of all lightning arresters provides a protection reliability of not less than..." the values we have just discussed. Therefore, how can we calculate them if in RD 34, we have got, e.g., the value of the first to the third lightning protection category, and we have protection zone A and zone B, respectively? I mean, how can we calculate such reliability? It is not clearly specified, which of them is designed for which system. SO-153 contains this information, but there are no special ties to the lightning protection class, i.e. to the lightning protection category, because it partially states the values that have been taken from IEC. But how can we calculate the actual reliability of the lightning protection system? SO-153 also contains the following phrase, if the facility is protected with the simple lightning arresters: single rod, single wire, double rod, double wire, closed wire, then, respectively, the lightning arresters' dimensions can be defined by using the protection zones specified in this regulatory document. It means that the formulas are provided in the regulatory document, and they cover only these simple lightning arrester systems, i.e. single rod, wire, double, and closed. What can we do if we, for example, have got the facility with varying heights, large number of lightning arresters, different types of lightning arresters, because they could be both wire and rod at the same time; and what can we do with them? I mean, how to obtain the actual reliability value? There is the following phrase in the document: "In general, the lightning arresters should be chosen using the respective software capable of calculating the protection zones or the probability of the lightning strike into the facility or a group of facilities of any configuration...",

Why do we need the service for calculation of the lightning protection reliability?

 Для чего нужен «сервис расчета надежности молниезащиты»? What do we need the “service for calculation of the lightning protection reliability”? Кто разработчик? Who is the developer? Какие параметры рассчитывает? What parameters can it calculate? Как перейти к ресурсу? How to access the service? ЭНИН ENIN ЭНЕРГЕТИЧЕСКИЙ ИНСТИТУТ им. Г. М. КРЖИЖАНОВСКОГО THE KRZHIZHANOVSKY ENERGY INSTITUTE ЗАЗЕМЛЕНО И ЗАЩИЩЕНО EARTHED AND PROTECTED

– The ZANDZ team has developed and implemented, in a trial mode, the service for calculation of the lightning protection reliability and the probability of the lightning strike irrespective of the presence of a lightning arrester. The computational core for this software has been developed by the laboratory for mathematical modelling of electrophysical processes under the guidance of Eduard Meerovich Bazelyan in the Krzhizhanovsky Energy Institute. You may access the service in two ways: either use a direct link you can see on the screen, or follow the link at ZANDZ.com. Let's use the direct link now.

Authorization or registration

 Авторизация или регистрация Authorization or registration Сервис расчетов надежности системы молниезащиты и вероятности прорыва молнии в объект Service for calculation of the reliability of the lightning protection system and the lightning breakthrough probability into the facility Авторизация: - ввести e-mail и пароль Authorization: - enter e-mail and password Регистрация: - зарегистрироваться на zandz.com Registration: - register at zandz.com

– We have accessed ZANDZ.com. To authorize and log onto the website as a user, you should be a registered user of ZANDZ.com. We will not show the registration process as we have already discussed it many times. Just in case, it is in the right upper corner. Here, you may press, fill in the form, and register. It means that you authorize and log into the service for calculation of the lightning protection using the link. I have already been authorized. If we follow the link, we will see this page, i.e. I have been authorized already. It will look like this.
